Accessori: ALLMTN 2

Engine

Yamaha, PW-X3, 250 Wh, 85 Nm

Display

Yamaha, Side Switch, 1.7″ LCD, 7 functions

Battery

Yamaha, InTube, 630 Wh

Frame family

Haibike, AllMtn PW-X3, Aluminium

Fork

RockShox, 35 Gold RL, Air, 160 mm travel, Aluminium steerer tube 1 1/8″ – 1 1/2″ tapered, 15 x 110mm thru-axle Boost

Damper

RockShox, Deluxe Select Plus, Air, Trunnion Mount

Crank arm

Haibike Components, The Crank ++, Aluminium

Brake (front)

TRP, Slate T4, Hydraulic disc brakes

Brake (rear)

TRP, Slate T4, Hydraulic disc brakes

Tube

Presta valve

Rim

WTB, ST i30 TCS, Double Wall

Clamping ring

Internal hexagon, 38.1 mm

Rear derailleur

Sram, SX Eagle

Shift lever

Sram, SX Eagle, Trigger switch

Bottom bracket

integrated in the motor

Sprocket

Sram, Eagle PG1210, 11 – 50 teeth

Chain

Sram, SX Eagle

Chainring

Sram, 38 teeth

Chain guide

Nylon directmount

Brake lever

TRP, Slate T4, Aluminium

Brake disc (front)

Tektro, TR203, 203 mm

Brake disc (rear)

Tektro, TR203, 203 mm

Tyre

Maxxis, Minion DHF II, 63-622, 29 x 2.5 inch

Front wheel hub

Haibike Components, The Hub ++, 6-bolt standard

Rear wheel hub

Haibike Components, TheHub ++ Thru axle 12×148, 6-bolt standard

Spokes

Sapim, Race

Handlebar

Haibike Components, TheBar +++, 780 mm

Grips

Haibike, MTB grips

Stem

Haibike Components, TheStem +++, 31.8 mm

Headset

Acros, BlockLock, Aluminium

Saddle

Selle Royal, Vivo

Seat post

Haibike Components, Dropper-Post Remote 34.9, Aluminium, Telescope, 34.9 mm

Pedals

Freeridepedal, Aluminium, with Reflector

Permitted total weight

150.0 kg

Tyre (rear)

Maxxis, Minion DHR II, 66-584, 27.5 x 2.6 inch

Rim (rear)

WTB, ST i35 TCS, Double Wall
